Silicon Carbide UHMWPE Hybrid Protection Plate NIJ III Plus 10x12 Inch SiC PE Composite Multi-Hit Armor Insert
Datos del producto:
| Lugar de origen: | Hunan, China |
| Nombre de la marca: | High Broad |
| Certificación: | NIJ 0101.06 Level III+, ISO 9001:2015 |
| Número de modelo: | HB-SIC-HYB-3P-1012 |
| Documento: | SIC Ballistic Armor Tiles-P...ad.pdf |
Pago y Envío Términos:
| Cantidad de orden mínima: | 10 piezas |
|---|---|
| Precio: | USD 20-75 / Piece |
| Detalles de empaquetado: | Envoltura individual de espuma EPE con caja corrugada y plataforma de madera contrachapada de export |
| Tiempo de entrega: | 5-7 días laborables para muestras, 15-25 días para pedidos al por mayor |
| Condiciones de pago: | T/T, L/C, Western Union, PayPal |
| Capacidad de la fuente: | 5000 piezas por mes |
|
Información detallada |
|||
| Material: | Carburo de silicio (SiC) + compuesto UHMWPE | Nivel de protección NIJ: | Nivel III+ (M80 OTAN + M855 Punta Verde) |
|---|---|---|---|
| Dimensiones: | 10 x 12 pulgadas (250 x 300 mm) | Espesor: | 10,5 mm (compuesto total) |
| Densidad regional: | 24,8 kg/m² | Peso: | 2,45 kg (plato único) |
| Dureza (cara de golpe): | 2600 HV (Knoop) | Espesor del respaldo de PE: | 6,5 mm |
| Espesor de la capa cerámica: | 4,0 milímetros | Capacidad de golpear varias veces: | 6 rondas M80 + 3 rondas M855 |
| Tipo de la curva: | Corte SAPI multicurva | Duración: | 10 años |
| Temperatura de funcionamiento: | -40°C a +70°C | ||
| Resaltar: | Silicon Carbide UHMWPE armor plate,NIJ III Plus bulletproof plate,10x12 inch SiC PE composite |
||
Descripción de producto
Silicon Carbide + UHMWPE Hybrid Protection Plate — The Ultimate Cost-Performance Formula
Why Hybrid Design Beats Pure Ceramic or Pure PE Every Time
| Armor Type | Weight (10x12) | NIJ Rating | M855 Stopped | Cost Index |
|---|---|---|---|---|
| SiC + UHMWPE Hybrid | 2.45 kg | III+ Special Threat | YES | 100% (baseline) |
| Alumina + PE Hybrid | 3.1 kg | III+ Special Threat | YES | 85% |
| Pure PE (UHMWPE Only) | 1.6 kg | III (M80 only) | NO | 110% |
| B₄C + PE Hybrid | 2.1 kg | III+ Special Threat | YES | 165% |
The HB-SIC-HYB-3P-1012 hybrid plate represents our optimized cost-performance design. By combining a 4.0mm SiC ceramic strike face with a 6.5mm UHMWPE composite backing, we achieve NIJ III+ special threat protection at a weight and price that neither pure ceramic nor pure PE can match.
- Alumina hybrid plates need thicker ceramic layers (6-7mm) to defeat M855, adding weight — our SiC hybrid is 21% lighter.
- Pure UHMWPE plates cannot stop M855 (SS109) penetrator rounds due to the steel tip piercing through the PE fibers — our SiC face shatters the penetrator on contact.
- Boron Carbide hybrids achieve similar performance but at a 65% cost premium — our SiC design gives you the same defeat capability at a fraction of the price.
Key Features
- NIJ III+ Special Threat Rated: Stops 7.62*51mm M80 NATO AND 5.56*45mm M855 (SS109) Green Tip penetrator rounds
- 4.0mm SiC Strike Face: Optimum thickness calculated for M855 steel penetrator defeat while minimizing weight
- 6.5mm UHMWPE Backing: Industry-standard High-grade PE laminate captures ceramic fragments and minimizes BFD
- Multi-Curve SAPI Cut: Anatomical fit for all-day wear comfort, compatible with standard SAPI/ESAPI plate carriers
- 6+3 Multi-Hit Proven: 6 rounds M80 plus 3 rounds M855 within the NIJ dispersion zone
Ideal For
- Protection units facing both 7.62mm and 5.56mm threats on the modern battlefield
- SWAT teams requiring M855/Green Tip defeat for urban operations
- Border patrol and counter-terrorism units needing multi-threat protection
Get the best cost-performance armor plate on the market. Contact our sales team for pricing, samples, and OEM branding options.
