Acid Resistant Metal-Free Boron Carbide Sandblast Nozzle with Long Venturi 45x8mm for Ceramic Surface Treatment
Datos del producto:
| Lugar de origen: | Hunan, China |
| Nombre de la marca: | High Broad |
| Certificación: | ISO 9001:2015 |
| Número de modelo: | HB-B4C |
| Documento: | Venturi nozzle Jane.pdf |
Pago y Envío Términos:
| Cantidad de orden mínima: | 10 piezas |
|---|---|
| Precio: | USD 10.00 - 28.00 / Piece |
| Detalles de empaquetado: | Caja individual revestida de espuma, cartón corrugado de calidad para exportación con barrera contra |
| Tiempo de entrega: | 3-5 días laborables para stock, 15-20 días para producción |
| Condiciones de pago: | T/T, L/C, PayPal, Western Union |
| Capacidad de la fuente: | 50000 piezas por mes |
|
Información detallada |
|||
| Tipo de boquilla: | Diámetro interior largo de Venturi | Hilo de conexión: | M16x1.5 |
|---|---|---|---|
| Diámetro interior: | 8mm | Longitud de la boquilla: | 45mm |
| Dureza: | ≥2800 nudos (HK) | Presión máxima de funcionamiento: | 0,8 MPa (116 PSI) |
| Resaltar: | Acid Alkali Resistant Nozzle,Zero Metal Contamination Design,Pure Ceramic Sandblast Tip |
||
Descripción de producto
Key Advantages
Zero Metal Contamination
100% B4C ceramic body with no metallic components. Eliminates ferrous and non-ferrous contamination during blasting — critical for semiconductor, medical device, and aerospace component processing.
Acid and Alkali Resistant
Outstanding chemical inertness against acidic and alkaline environments. Performs reliably in wet blasting with chemical additives without material degradation.
Long Venturi Design
45mm extended venturi bore with 8mm diameter maximizes particle acceleration distance. Delivers superior blasting uniformity across large surface areas.
Ceramic Surface Ready
Optimized for ceramic, glass, quartz, and other brittle material surface treatments. Gentle yet effective abrasive flow preserves substrate integrity.
Technical Specifications
| Material | Boron Carbide (B4C) Ceramic |
| Nozzle Type | Long Venturi Bore |
| Bore Diameter | 8mm |
| Nozzle Length | 45mm |
| Metal Content | Zero (100% ceramic) |
| Chemical Resistance | Excellent acid/alkali resistance |
| Hardness | ≥2800 HK (Knoop) |
| Max Operating Pressure | 0.8 MPa (116 PSI) |
Applications
- Semiconductor wafer and component surface treatment
- Medical implant and surgical instrument finishing
- Ceramic and glass substrate etching and texturing
- Aerospace turbine blade coating preparation
- Precision optical component cleaning
