High Temperature Boron Carbide Sandblasting Nozzle with 600°C Max Operating Temperature and Thermal Shock Resistant 30x6mm Straight Bore
Datos del producto:
| Lugar de origen: | Hunan, China |
| Nombre de la marca: | High Broad |
| Certificación: | ISO 9001:2015 |
| Número de modelo: | HB-B4C |
| Documento: | Venturi nozzle Jane.pdf |
Pago y Envío Términos:
| Cantidad de orden mínima: | 10 piezas |
|---|---|
| Precio: | USD 9.00 - 22.00 / Piece |
| Detalles de empaquetado: | Caja individual revestida de espuma, cartón corrugado de calidad para exportación con barrera contra |
| Tiempo de entrega: | 3-5 días laborables para stock, 15-20 días para producción |
| Condiciones de pago: | T/T, L/C, PayPal, Western Union |
| Capacidad de la fuente: | 50000 piezas por mes |
|
Información detallada |
|||
| Densidad: | ≥2,48 g/cm³ | Temperatura máxima de funcionamiento: | 600°C |
|---|---|---|---|
| Longitud de la boquilla: | 30mm | Presión máxima de funcionamiento: | 0,8 MPa (116 PSI) |
| Hilo de conexión: | M12x1.5 | Resistencia al choque térmico: | Excelente (ΔT ≥ 400°C) |
| Resaltar: | High Temperature Nozzle,Thermal Shock Resistant Sandblast,Heavy Duty Blasting Nozzle |
||
Descripción de producto
Key Advantages
High Temperature Endurance
Maintains full mechanical strength and wear resistance at continuous operating temperatures up to 600°C. No softening, deformation, or performance degradation in hot blasting environments.
Thermal Shock Proof
Withstands rapid temperature changes exceeding ΔT 400°C without cracking or spalling. Safe for intermittent hot-surface blasting where thermal cycling is unavoidable.
Focused Straight Bore
30mm straight bore with 6mm diameter concentrates abrasive energy into a tight, high-impact stream. Ideal for spot blasting, weld cleaning, and precision rust removal on hot surfaces.
Heavy Duty Construction
Thick-walled B4C ceramic body withstands high-pressure blasting at 0.8 MPa. Designed for the toughest foundry, shipyard, and steel mill environments.
Technical Specifications
| Material | Boron Carbide (B4C) Ceramic |
| Nozzle Type | Straight Bore |
| Bore Diameter | 6mm |
| Nozzle Length | 30mm |
| Max Temperature | 600°C |
| Thermal Shock ΔT | ≥400°C |
| Hardness | ≥2800 HK (Knoop) |
| Max Operating Pressure | 0.8 MPa (116 PSI) |
Applications
- Foundry casting cleaning and descaling at elevated temperatures
- Hot forging scale removal and surface preparation
- Steel mill roll and equipment maintenance blasting
- Heat exchanger tube and boiler cleaning
- Weld seam cleaning on preheated heavy steel structures
